Temperature Range:
-40℃ + 180℃ ±1℃
-70℃ + 180℃ ±1℃
Humidity Range: 20% to 98%, ±3% RH
Dew Point Range: +4℃ to +85℃
Climate Range: +25℃ to +85℃
Rate of Change of Temperature:
#3℃ / Minute
#5℃ / Minute
#10℃ / Minute
#15℃ / Minute
Options: Altitude up to 100000 feet
Walk-in chambers available on request
Ess chambers available on request
| Model No. | Volume (Liters) | W (MM) | D (MM) | H (MM) |
|---|---|---|---|---|
| HLH-120 | 120 | 450 | 450 | 600 |
| HLH-200 | 200 | 600 | 600 | 600 |
| HLH-500 | 500 | 750 | 750 | 900 |
| HLH-1000 | 1000 | 1000 | 1000 | 1000 |
*Test Space can be provided as per customer requirement.
* All performance measured at Room temperature / Ambient of ±25℃ to ±2℃
* Appearance & Design of Chamber may vary depending on the internal dimension
• Dual loop Microprocessor programmer, Touchscreen based HMI with ethernet facility.
• Unlimited real time recording of temperature measured values versus time (log on Pen Drive).
• Recordings in CSV format (Comma Separated Value) for easy export to Excel® to Pendrive via USB interface placed on the front panel.
• Cycles as per requirement can be programmed directly from the touchscreen.
• Remote Monitoring through PC on Ethernet with VNC. VNC will be free download version.
• Air cooled / Water cooled Semi Hermetic type. CFC free refrigeration system Performance Conform IS 9000, DEF-STD-133, IEC 68 Specifications
